Integrating C++ Drivers into C-Based Firmware

Story

Imagine this scenario: you are working on a firmware project written entirely in C. Midway through development, your team finds a new sensor that is 10× cheaper than the current one. Naturally, management wants it integrated into the next hardware version.

Here’s the catch — the official driver for this sensor is only available in C++.

Now, instead of rewriting the entire driver in C (which is time-consuming and error-prone), you can integrate the C++ driver into your C-based firmware with minimal changes.

There are a couple of ways to achieve this quickly.

1. Expose C++ classes as a c API ( Recommended )

Since C does not understand C++ classes, we can build a C wrapper around the C++ code.

This approach works by providing extern “C” functions that operate on opaque pointers to C++ objects. Opaque pointers allow us to manage class instances in C without exposing their internal structure.

Let’s look at the project structure:

This wrapper creates new C++ class instances, exposes them as opaque pointers, and provides simple C functions that forward calls to the underlying C++ methods.

below you can find the actual code related to all this files.

#pragma once
#include <string>

class Driver {
public:
    Driver(const std::string &name);
    ~Driver();

    void sayHello();
private:
    std::string name_;
};

#include "Driver.hpp"
#include <iostream>

Driver::Driver(const std::string &name) : name_(name) {}

Driver::~Driver() {}

void Driver::sayHello() {
    std::cout << "Hello, " << name_ << "!" << std::endl;
}

#pragma once

#ifdef __cplusplus
extern "C" {
#endif

// Use opaque pointer for the class
typedef void* DriverHandle;

DriverHandle Driver_create(const char* name);
void Driver_destroy(DriverHandle obj);
void Driver_sayHello(DriverHandle obj);

#ifdef __cplusplus
}
#endif

#include "Driver.hpp"
#include "Driver_C_Wrapper.h"

extern "C" {

DriverHandle Driver_create(const char* name) {
    return new Driver(name);
}

void Driver_destroy(DriverHandle obj) {
    delete static_cast<Driver*>(obj);
}

void Driver_sayHello(DriverHandle obj) {
    static_cast<Driver*>(obj)->sayHello();
}

}

#include "Driver_C_Wrapper.h"

int main() {
    DriverHandle obj = Driver_create("Saurabh");
    Driver_sayHello(obj);
    Driver_destroy(obj);
    return 0;
}

cmake_minimum_required(VERSION 3.10)
project(test C CXX)

set(CMAKE_C_STANDARD 99)
set(CMAKE_CXX_STANDARD 11)

# Create library from C++ code
add_library(Driver STATIC
    Driver.cpp
    Driver_C_Wrapper.cpp
)

# Main C program
add_executable(main main.c)

# Link C++ library into C program
target_link_libraries(main PRIVATE Driver)

2. Compile C code with a C++ Compiler

If your project is mostly C but you can switch the compiler (for example, .c files compiled as C++), then you don’t need wrappers. Just rename .c files to .cpp (or use g++/clang++ with -x c++) and include your class directly.

For example, you can rename .c files to .cpp (or tell the compiler to treat them as C++ using flags like -x c++) and then include the C++ driver headers directly.
